Aaris provides precision tubular products for the hydraulic cylinder, pneumatic cylinder and flow control devices.
The products we offer for this application are:
Tube – Welded Drawn-Over-Mandrel
- Specifications: ASTM A513 T5, T6 (SSID), EN 10305-2
- Grades: 1010, 1018, 1020, 1026, 4130, E 215, E235, E355
- Size Range: 0.375”-6.000” OD up to 0.375” wall
- 9.5mm-152.4mm OD, up to 11.1 wall
Tube – Seamless Cold Drawn
- Specifications: ASTM A519, DIN 2391
- Grades: 1020, 1026, 1035, 1040, ST52
- Size Range: 1.500”-20” OD up to 2.000” wall
- 12.7mm – 457.2mm OD, up to 50.8mm wall
Tube – Welded Hydraulic
- Specifications: ASTM A214, SAE J525,
- Grades: 1008, 1010
- Size Range: 0.250”-2.500” OD up to 0.134” wall
- 6.4mm-63.5mm OD, up to 3.4mm wall
Tube – Seamless Hydraulic
- Specifications: ASTM A179, SAE J524
- Grades: 1008, 1010, 1018
- Size Range: 0.125”- 2.000” OD up to 0.134” wall
- 3.2mm – 50.8mm OD, up to 3.4mm wall
Tube – ERW Hydraulic
- Specifications: SAE J526
- Grades: 1008, 1010
- Size Range: 0.250”-2.000”, 0.035”-0.120” wall
- 6.4mm – 50.8mm OD, 0.9mm – 3.0mm wall
Tube – Brazed Hydraulic
- Specifications: SAE J527
- Grades: 1004-1008
- Size Range: 0.188”, 0.250”, 0.313” – 0.028” wall
- 4.8mm, 6.4mm, 7.9mm OD; .71mm wall
- Surface Coating- Bare, Galfan, Al/ Gal, Nylon
Tube – Seamless Aluminum
- Specifications: ASTM B210, B241
- Grades: 6061, 6063, 3000 series, 7000 series
- Size Range: 0.125”-4.000” OD up to 0.500” wall
- 3.2mm – 101.6mm OD, up to 12.7mm
Bars – Chrome Bars
- Specifications: CPO 50/75/100; IHCP 100, 0.0005”/0.001” Chrome
- Grades: 1045, 1045V, 1050, 4140
- Size Range: 0.500”- 6.000”
- 12.7mm – 152.4mm
